| panel size |
|
||||
| model size | 503.6(H)*331.8(V)mm without bracket | ||||
| Ratio | 16:9 | ||||
| Density | 0.094(H)x0.282(V)mm | ||||
| Pixel pitch | 0.282H)x0.282(V)mm | ||||
| viewing area | 481.5(H)X312.7(V)mm | ||||
| display area | 473.76(H)X296.1(V)mm | ||||
| Brightness(Typical values) | 250cd/m² | ||||
| Contrast(Typical values) | 20000000:1(Dynamic) | ||||
| Viewing Angle(H/V) | 160/170 | ||||
| Response time | 5ms | ||||
| Recommended resolution | 1680*1050 | ||||
| Color display | 16.7M | ||||
| Interface | VGA&HDMI | ||||
| Power | External DC power supply | ||||
| Consumed power | Working:19W (Typical values) Standby:<0.5W | ||||
| Plug and play | Support | ||||
| User control | Automatically adjust/Power switch | ||||
| OSD language | Optional | ||||
| Speaker | Optional | ||||
| Installation | Bracket,Wall-hanging | ||||
| Case color | Black | ||||
| Structure function | Bracket tilt:-4°-14° | ||||
| Haze | 25% | ||||
| Hard coating | 3H |
